mlt_frame.h File Reference

interface for all frame classes More...

#include "mlt_audio.h"
#include "mlt_deque.h"
#include "mlt_image.h"
#include "mlt_properties.h"
#include "mlt_service.h"

Go to the source code of this file.

Data Structures
struct	mlt_frame_s
	Frame class. More...

Macros
#define	MLT_FRAME_AUDIO_STACK(frame)   ((frame)->stack_audio)
#define	MLT_FRAME_IMAGE_STACK(frame)   ((frame)->stack_image)
#define	MLT_FRAME_PROPERTIES(frame)   (&(frame)->parent)
#define	MLT_FRAME_SERVICE_STACK(frame)   ((frame)->stack_service)
#define	RGB2UV_601_SCALED(r, g, b, u, v)
	This macro scales RGB into the YUV gamut - uv is scaled by 224/255 (y unused). More...
#define	RGB2YUV_601_SCALED(r, g, b, y, u, v)
	This macro scales RGB into the YUV gamut - y is scaled by 219/255 and uv by 224/255. More...
#define	YUV2RGB_601_SCALED(y, u, v, r, g, b)
	This macro scales YUV up into the full gamut of the RGB color space. More...

Typedefs
typedef int(*	mlt_get_audio) (mlt_frame self, void **buffer, mlt_audio_format *format, int *frequency, int *channels, int *samples)
	Callback function to get audio data. More...
typedef int(*	mlt_get_image) (mlt_frame self, uint8_t **buffer, mlt_image_format *format, int *width, int *height, int writable)
	Callback function to get video data. More...

Functions
mlt_frame	mlt_frame_clone (mlt_frame self, int is_deep)
mlt_frame	mlt_frame_clone_audio (mlt_frame self, int is_deep)
mlt_frame	mlt_frame_clone_image (mlt_frame self, int is_deep)
void	mlt_frame_close (mlt_frame self)
uint8_t *	mlt_frame_get_alpha (mlt_frame self)
uint8_t *	mlt_frame_get_alpha_size (mlt_frame self, int *size)
double	mlt_frame_get_aspect_ratio (mlt_frame self)
int	mlt_frame_get_audio (mlt_frame self, void **buffer, mlt_audio_format *format, int *frequency, int *channels, int *samples)
int	mlt_frame_get_image (mlt_frame self, uint8_t **buffer, mlt_image_format *format, int *width, int *height, int writable)
mlt_producer	mlt_frame_get_original_producer (mlt_frame self)
mlt_position	mlt_frame_get_position (mlt_frame self)
mlt_properties	mlt_frame_get_unique_properties (mlt_frame self, mlt_service service)
unsigned char *	mlt_frame_get_waveform (mlt_frame self, int w, int h)
mlt_frame	mlt_frame_init (mlt_service service)
int	mlt_frame_is_test_audio (mlt_frame self)
int	mlt_frame_is_test_card (mlt_frame self)
mlt_position	mlt_frame_original_position (mlt_frame self)
void *	mlt_frame_pop_audio (mlt_frame self)
mlt_frame	mlt_frame_pop_frame (mlt_frame self)
mlt_get_image	mlt_frame_pop_get_image (mlt_frame self)
void *	mlt_frame_pop_service (mlt_frame self)
int	mlt_frame_pop_service_int (mlt_frame self)
mlt_properties	mlt_frame_properties (mlt_frame self)
int	mlt_frame_push_audio (mlt_frame self, void *that)
int	mlt_frame_push_frame (mlt_frame self, mlt_frame that)
int	mlt_frame_push_get_image (mlt_frame self, mlt_get_image get_image)
int	mlt_frame_push_service (mlt_frame self, void *that)
int	mlt_frame_push_service_int (mlt_frame self, int that)
void	mlt_frame_replace_image (mlt_frame self, uint8_t *image, mlt_image_format format, int width, int height)
mlt_deque	mlt_frame_service_stack (mlt_frame self)
int	mlt_frame_set_alpha (mlt_frame self, uint8_t *alpha, int size, mlt_destructor destroy)
int	mlt_frame_set_aspect_ratio (mlt_frame self, double value)
int	mlt_frame_set_audio (mlt_frame self, void *buffer, mlt_audio_format, int size, mlt_destructor)
int	mlt_frame_set_image (mlt_frame self, uint8_t *image, int size, mlt_destructor destroy)
int	mlt_frame_set_position (mlt_frame self, mlt_position value)
mlt_properties	mlt_frame_unique_properties (mlt_frame self, mlt_service service)
void	mlt_frame_write_ppm (mlt_frame frame)

Detailed Description

interface for all frame classes

See also

mlt_frame_s

Copyright (C) 2003-2023 Meltytech, LLC

This library is free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation; either version 2.1 of the License, or (at your option) any later version.

This library is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License for more details.

You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA

Macro Definition Documentation

MLT_FRAME_AUDIO_STACK

#define MLT_FRAME_AUDIO_STACK

(

frame

)

((frame)->stack_audio)

MLT_FRAME_IMAGE_STACK

#define MLT_FRAME_IMAGE_STACK

(

frame

)

((frame)->stack_image)

MLT_FRAME_PROPERTIES

#define MLT_FRAME_PROPERTIES

(

frame

)

(&(frame)->parent)

MLT_FRAME_SERVICE_STACK

#define MLT_FRAME_SERVICE_STACK

(

frame

)

((frame)->stack_service)

RGB2UV_601_SCALED

#define RGB2UV_601_SCALED	(		r,
			g,
			b,
			u,
			v
	)

Value:

    u = ((-152 * r - 300 * g + 450 * b) >> 10) + 128; \
    v = ((450 * r - 377 * g - 73 * b) >> 10) + 128;

This macro scales RGB into the YUV gamut - uv is scaled by 224/255 (y unused).

RGB2YUV_601_SCALED

#define RGB2YUV_601_SCALED	(		r,
			g,
			b,
			y,
			u,
			v
	)

Value:

    y = ((263 * r + 516 * g + 100 * b) >> 10) + 16; \
    u = ((-152 * r - 300 * g + 450 * b) >> 10) + 128; \
    v = ((450 * r - 377 * g - 73 * b) >> 10) + 128;

This macro scales RGB into the YUV gamut - y is scaled by 219/255 and uv by 224/255.

YUV2RGB_601_SCALED

#define YUV2RGB_601_SCALED	(		y,
			u,
			v,
			r,
			g,
			b
	)

Value:

    r = ((1192 * (y - 16) + 1634 * (v - 128)) >> 10); \
    g = ((1192 * (y - 16) - 832 * (v - 128) - 401 * (u - 128)) >> 10); \
    b = ((1192 * (y - 16) + 2066 * (u - 128)) >> 10); \
    r = r < 0 ? 0 : r > 255 ? 255 : r; \
    g = g < 0 ? 0 : g > 255 ? 255 : g; \
    b = b < 0 ? 0 : b > 255 ? 255 : b;

This macro scales YUV up into the full gamut of the RGB color space.

Typedef Documentation

mlt_get_audio

typedef int(* mlt_get_audio) (mlt_frame self, void **buffer, mlt_audio_format *format, int *frequency, int *channels, int *samples)

Callback function to get audio data.

mlt_get_image

typedef int(* mlt_get_image) (mlt_frame self, uint8_t **buffer, mlt_image_format *format, int *width, int *height, int writable)

Callback function to get video data.

Function Documentation

mlt_frame_clone()

mlt_frame mlt_frame_clone	(	mlt_frame	self,
		int	is_deep
	)

mlt_frame_clone_audio()

mlt_frame mlt_frame_clone_audio	(	mlt_frame	self,
		int	is_deep
	)

mlt_frame_clone_image()

mlt_frame mlt_frame_clone_image	(	mlt_frame	self,
		int	is_deep
	)

mlt_frame_close()

void mlt_frame_close

(

mlt_frame

self

)

mlt_frame_get_alpha()

uint8_t* mlt_frame_get_alpha

(

mlt_frame

self

)

mlt_frame_get_alpha_size()

uint8_t* mlt_frame_get_alpha_size	(	mlt_frame	self,
		int *	size
	)

mlt_frame_get_aspect_ratio()

double mlt_frame_get_aspect_ratio

(

mlt_frame

self

)

mlt_frame_get_audio()

int mlt_frame_get_audio	(	mlt_frame	self,
		void **	buffer,
		mlt_audio_format *	format,
		int *	frequency,
		int *	channels,
		int *	samples
	)

mlt_frame_get_image()

int mlt_frame_get_image	(	mlt_frame	self,
		uint8_t **	buffer,
		mlt_image_format *	format,
		int *	width,
		int *	height,
		int	writable
	)

mlt_frame_get_original_producer()

mlt_producer mlt_frame_get_original_producer

(

mlt_frame

self

)

mlt_frame_get_position()

mlt_position mlt_frame_get_position

(

mlt_frame

self

)

mlt_frame_get_unique_properties()

mlt_properties mlt_frame_get_unique_properties	(	mlt_frame	self,
		mlt_service	service
	)

mlt_frame_get_waveform()

unsigned char* mlt_frame_get_waveform	(	mlt_frame	self,
		int	w,
		int	h
	)

mlt_frame_init()

mlt_frame mlt_frame_init

(

mlt_service

service

)

mlt_frame_is_test_audio()

int mlt_frame_is_test_audio

(

mlt_frame

self

)

mlt_frame_is_test_card()

int mlt_frame_is_test_card

(

mlt_frame

self

)

mlt_frame_original_position()

mlt_position mlt_frame_original_position

(

mlt_frame

self

)

mlt_frame_pop_audio()

void* mlt_frame_pop_audio

(

mlt_frame

self

)

mlt_frame_pop_frame()

mlt_frame mlt_frame_pop_frame

(

mlt_frame

self

)

mlt_frame_pop_get_image()

mlt_get_image mlt_frame_pop_get_image

(

mlt_frame

self

)

mlt_frame_pop_service()

void* mlt_frame_pop_service

(

mlt_frame

self

)

mlt_frame_pop_service_int()

int mlt_frame_pop_service_int

(

mlt_frame

self

)

mlt_frame_properties()

mlt_properties mlt_frame_properties

(

mlt_frame

self

)

mlt_frame_push_audio()

int mlt_frame_push_audio	(	mlt_frame	self,
		void *	that
	)

mlt_frame_push_frame()

int mlt_frame_push_frame	(	mlt_frame	self,
		mlt_frame	that
	)

mlt_frame_push_get_image()

int mlt_frame_push_get_image	(	mlt_frame	self,
		mlt_get_image	get_image
	)

mlt_frame_push_service()

int mlt_frame_push_service	(	mlt_frame	self,
		void *	that
	)

mlt_frame_push_service_int()

int mlt_frame_push_service_int	(	mlt_frame	self,
		int	that
	)

mlt_frame_replace_image()

void mlt_frame_replace_image	(	mlt_frame	self,
		uint8_t *	image,
		mlt_image_format	format,
		int	width,
		int	height
	)

mlt_frame_service_stack()

mlt_deque mlt_frame_service_stack

(

mlt_frame

self

)

mlt_frame_set_alpha()

int mlt_frame_set_alpha	(	mlt_frame	self,
		uint8_t *	alpha,
		int	size,
		mlt_destructor	destroy
	)

mlt_frame_set_aspect_ratio()

int mlt_frame_set_aspect_ratio	(	mlt_frame	self,
		double	value
	)

mlt_frame_set_audio()

int mlt_frame_set_audio	(	mlt_frame	self,
		void *	buffer,
		mlt_audio_format	,
		int	size,
		mlt_destructor
	)

mlt_frame_set_image()

int mlt_frame_set_image	(	mlt_frame	self,
		uint8_t *	image,
		int	size,
		mlt_destructor	destroy
	)

mlt_frame_set_position()

int mlt_frame_set_position	(	mlt_frame	self,
		mlt_position	value
	)

mlt_frame_unique_properties()

mlt_properties mlt_frame_unique_properties	(	mlt_frame	self,
		mlt_service	service
	)

mlt_frame_write_ppm()

void mlt_frame_write_ppm

(

mlt_frame

frame

)
