multitrack service class More...

#include "mlt_export.h"
#include "mlt_producer.h"

Data Structures
struct	mlt_multitrack_s
	Multitrack class. More...

struct	mlt_track_s
	Track class used by mlt_multitrack_s. More...

Macros
#define	MLT_MULTITRACK_PRODUCER(multitrack) (&(multitrack)->parent)

#define	MLT_MULTITRACK_PROPERTIES(multitrack) MLT_SERVICE_PROPERTIES(MLT_MULTITRACK_SERVICE(multitrack))

#define	MLT_MULTITRACK_SERVICE(multitrack) MLT_PRODUCER_SERVICE(MLT_MULTITRACK_PRODUCER(multitrack))

Typedefs
typedef struct mlt_track_s *	mlt_track

Functions
MLT_EXPORT mlt_position	mlt_multitrack_clip (mlt_multitrack self, mlt_whence whence, int index)

MLT_EXPORT void	mlt_multitrack_close (mlt_multitrack self)

MLT_EXPORT int	mlt_multitrack_connect (mlt_multitrack self, mlt_producer producer, int track)

MLT_EXPORT int	mlt_multitrack_count (mlt_multitrack self)

MLT_EXPORT int	mlt_multitrack_disconnect (mlt_multitrack self, int track)

MLT_EXPORT mlt_multitrack	mlt_multitrack_init ()

MLT_EXPORT int	mlt_multitrack_insert (mlt_multitrack self, mlt_producer producer, int track)

MLT_EXPORT mlt_producer	mlt_multitrack_producer (mlt_multitrack self)

MLT_EXPORT mlt_properties	mlt_multitrack_properties (mlt_multitrack self)

MLT_EXPORT void	mlt_multitrack_refresh (mlt_multitrack self)

MLT_EXPORT mlt_service	mlt_multitrack_service (mlt_multitrack self)

MLT_EXPORT mlt_producer	mlt_multitrack_track (mlt_multitrack self, int track)

Detailed Description

multitrack service class

See also: mlt_multitrack_s

This library is free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation; either version 2.1 of the License, or (at your option) any later version.

This library is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License for more details.

You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA

Macro Definition Documentation

◆ MLT_MULTITRACK_PRODUCER

#define MLT_MULTITRACK_PRODUCER ( multitrack ) (&(multitrack)->parent)

◆ MLT_MULTITRACK_PROPERTIES

#define MLT_MULTITRACK_PROPERTIES ( multitrack ) MLT_SERVICE_PROPERTIES(MLT_MULTITRACK_SERVICE(multitrack))

◆ MLT_MULTITRACK_SERVICE

#define MLT_MULTITRACK_SERVICE ( multitrack ) MLT_PRODUCER_SERVICE(MLT_MULTITRACK_PRODUCER(multitrack))

Typedef Documentation

◆ mlt_track

typedef struct mlt_track_s* mlt_track

Function Documentation

◆ mlt_multitrack_clip()

MLT_EXPORT mlt_position mlt_multitrack_clip	(	mlt_multitrack	self,
		mlt_whence	whence,
		int	index
	)

◆ mlt_multitrack_close()

MLT_EXPORT void mlt_multitrack_close ( mlt_multitrack self )

◆ mlt_multitrack_connect()

MLT_EXPORT int mlt_multitrack_connect	(	mlt_multitrack	self,
		mlt_producer	producer,
		int	track
	)

◆ mlt_multitrack_count()

MLT_EXPORT int mlt_multitrack_count ( mlt_multitrack self )

◆ mlt_multitrack_disconnect()

MLT_EXPORT int mlt_multitrack_disconnect	(	mlt_multitrack	self,
		int	track
	)

◆ mlt_multitrack_init()

MLT_EXPORT mlt_multitrack mlt_multitrack_init ( )

◆ mlt_multitrack_insert()

MLT_EXPORT int mlt_multitrack_insert	(	mlt_multitrack	self,
		mlt_producer	producer,
		int	track
	)

◆ mlt_multitrack_producer()

MLT_EXPORT mlt_producer mlt_multitrack_producer ( mlt_multitrack self )

◆ mlt_multitrack_properties()

MLT_EXPORT mlt_properties mlt_multitrack_properties ( mlt_multitrack self )

◆ mlt_multitrack_refresh()

MLT_EXPORT void mlt_multitrack_refresh ( mlt_multitrack self )

◆ mlt_multitrack_service()

MLT_EXPORT mlt_service mlt_multitrack_service ( mlt_multitrack self )

◆ mlt_multitrack_track()

MLT_EXPORT mlt_producer mlt_multitrack_track	(	mlt_multitrack	self,
		int	track
	)
